- General Information
- Manufacturer
- The Bosch Group
- Manufacturer Website Address
- http://www.bosch.com
- Brand Name
- Electro-Voice
- Product Type
- Speaker
- 1200 W (peak), 128 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices.
- 1.4 inch DH-1C (1 inch exit) titanium compression driver for extended transparent high-frequency response
- High-output EVS-12M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
- EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
- Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX three-handle design for easy lifting.
Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The full-range models feature a low profile form factor designed with a high-spec composite enclosure to balance weight, manageability, as well as structural integrity. The proprietary features that have made the other members of the EV portable speaker family a goto for best-in-class performance are also present: Signal Synchronized Transducers (SST) waveguide concept.
EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system's highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.
- Technical Information
- Crossover Type
- 2-way
- RMS Output Power
- 300 W
- PMPO Output Power
- 1200 W
- Woofer Driver Size
- 12"
- Tweeter Driver Size
- 1"
- Tweeter Driver Material
- Titanium
- Minimum Frequency Response
- 77 Hz
- Maximum Frequency Response
- 17 kHz
- Impedance
- 8 Ohm
- Sensitivity
- 93 dB
- Physical Characteristics
- Product Color
- Black
- Form Factor
- Wall Mountable
- Height
- 24.8"
- Width
- 14.3"
- Depth
- 13.54"
- Weight (Approximate)
- 33.51 lb
- Miscellaneous
- Country of Origin
- China
