- General Information
- Manufacturer
- Transcend Information, Inc
- Manufacturer Website Address
- http://www.transcend-info.com
- Brand Name
- Transcend
- Product Type
- RAM Module
The TS1GLK64V3H is a 1G x 64bits DDR3-1333 2Rank Unbuffered DIMM. The TS1GLK64V3H consists of 16pcs 512Mx8 bits DDR3 SDRAMs and a 2048 bits serial EEPROM on a 240-pin printed circuit board. The TS1GLK64V3H is a Dual In-Line Memory Module and is intended for mounting into 240-pin edge connector sockets.
Synchronous design allows precise cycle control with the use of system clock. Data I/O transactions are possible on both edges of DQS. Range of operation frequencies, programmable latencies allow the same device to be useful for a variety of high bandwidth, high performance memory system applications.
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Memory Size
- 8 GB
- Memory Technology
- DDR3 SDRAM
- Number of Modules
- 1 x 8GB
- Memory Speed
- 1333 MHz
- Memory Standard
- DDR3-1333/PC3-10600
- Error Checking
- Non-ECC
- Signal Processing
- Unbuffered
- CAS Latency
- CL9
- Device Supported
- Desktop PC
- Physical Characteristics
- Number of Pins
- 240-pin
- Form Factor
- DIMM
- Thickness
- 50 mil
- Width
- 1.2"
- Length
- 5.3"
- Miscellaneous
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
