- General Information
- Manufacturer
- Shuttle, Inc
- Manufacturer Website Address
- http://www.us.shuttle.com
- Brand Name
- Shuttle
- Product Line
- XPC slim
- Product Type
- Barebone System
FLEXIBLE 3-LITRE PC WITH PCIE SLOT
The Shuttle XPC slim Barebone XH510G is a 3-litre PC to house one single-slot PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible
- Processor
- Number of Processors Supported
- 1
- Processor Socket
- Socket LGA-1200
- Processor Supported
- Core i3
- Core i5
- Core i7
- Core i9
- Pentium Gold
- Celeron
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- H510
- Memory
- Maximum Memory Supported
- 64 GB
- Memory Technology
- DDR4 SDRAM
- Memory Standard
- DDR4-3200/PC4-25600
- Total Number of Memory Slots
- 2.0
- Storage
- Supported Storage Drive Interfaces
- Serial ATA III
- Supported Storage Drive Types
- SSD
- HDD
- Controllers
- Controller Type
- Serial ATA/600
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- I/O Expansions
- Number of Total Expansion Bays
- 1
- Total Number of Expansion Slots
- 1.0
- Number of PCI Express x16 Slots
- 1
- Interfaces/Ports
- HDMI (Rear)
- Yes
- Total Number of USB Ports
- 8
- Number of USB 3.2 Gen 1 Ports
- 4
- Operating System
- Operating System Supported
- Windows 10 x64
- Windows 11 x64
- Linux
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Power Supply Wattage
- 180 W
- Physical Characteristics
- Height
- 3.1"
- Width
- 7.9"
- Depth
- 9.8"
- Weight (Approximate)
- 4.19 lb
- Miscellaneous
- Package Contents
- XPC slim XH510G Barebone System
- Multi-language installation guide (EN, DE, FR, ES, JP, KR, SC, TC)
- DVD Driver
- Bracket for one 2.5" drive
- 4 x Screws M3 x 4 mm
- 3 x Screws M2 x 5 mm
- VESA Mount Brackets
- 4 x Screws M3 x 5 mm
- 4 x Screws M4 x 10 mm
- 3 x Screws M3 x 5 mm
- Internal Adapter Cable with 4-Pin Molex Connector for 5v/2a Auxiliary Voltage
- External Power Adapter With 1.7 M Power Cord With Earthing Contact
- Protector Cap for the CPU Socket (do not use if heat-pipe or fan is mounted)
- CPU Heatpipe Cooling System with Heatsink Compound
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- ENERGY STAR 8.0
- Energy Efficiency Compliance
- Energy-related Products Directive (ErP)
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
