- General Information
- Manufacturer
- Juniper Networks, Inc
- Manufacturer Website Address
- http://www.juniper.net
- Brand Name
- Juniper
- Product Series
- ACX
- Product Type
- Router
Many networks have seen benefits from convergence in the core and the edge, a similar transformation is clearly required in the access network. Universal Access is an architectural concept that achieves this objective by extending operational intelligence from the edge to access network. Juniper Networks ACX Series Universal Access Routers are purpose built to support adaptive services architecture, enabling rapid deployment of access services and transforming the network to create a seamless end-to-end service delivery platform. ACX series being a family of hardened universal access routers can be deployed in a variety of service provider use cases namely, mobile backhaul, residential and business access, as well as mission critical enterprise use cases demanding high availability operation in extreme environments such as power utilities, oil & gas, mining, transportation, defense and public safety industries.
- Warranty
- Limited Warranty
- 1 Year
- Interfaces/Ports
- Total Number of Ports
- 12
- USB
- Yes
- Powerline
- No
- Management Port
- Yes
- Token Ring Port
- No
- Serial V.35 Interface
- No
- Number of Network (RJ-45) Ports
- 12
- I/O Expansions
- Total Number of Expansion Slots
- 4.0
- Expansion Slot Type
- SFP
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- Power Description
- PoE (RJ-45) Port
- No
- Input Voltage
- 24 V DC
- Redundant Power Supply Supported
- Yes
- Power Source
- Power Supply
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 1.8"
- Width
- 17.5"
- Depth
- 9.4"
- Weight (Approximate)
- 7.80 lb
- Miscellaneous
- Package Contents
- ACX1100-AC Router
- Redundant AC Power Supply
- Certifications & Standards
Safety Approvals:
- CAN/CSA-C22.2 No. 60950-1
- UL 60950-1
- EN 60950-1
- IEC 60950-1 - CB Scheme
- EN 60825-1
EMC:
- AS/NZS CISPR22 Class A
- EN55022 Class A
- VCCI Class B
- FCC Part 15 Class A
Immunity:
- EN-61000-3-2
- EN-61000-3-3
- EN-61000-4-2
- EN-61000-4-3
- EN-61000-4-4
- EN-61000-4-5
- EN-61000-4-6
- EN-61000-4-11
ETSI:
- ETSI EN300386-2
- ETSI EN 300 019-2-1 (2000)
- ETSI EN 300 019-2-2 (1999)
- ETSI EN 300 019-2-3 (2003)
- ETSI EN 300 019-2-4 (2003)
- ETS 300753 (1997)
NEBS:
- SR-3580 NEBS Criteria Levels (Level 3 Compliance)
- GR-63-CORE
- GR-1089-CORE
- GR-3108-CORE
Telecomm Compliance:
- RTTE Directive 1995/5/EC
- FCC Part 68
- Industry Canada CS-03
- JATE Green Book
- TBR 21 (XDSL only)
- TBR 12/13
- ACA TS016
- G.703
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
