- General Information
- Manufacturer
- Fluke Networks
- Manufacturer Website Address
- http://www.flukenetworks.com
- Brand Name
- Fluke
- Product Type
- Multimeter
Product overview: Fluke 116 HVAC Multimeter with Temperature and Microamps | Fluke 116 HVAC Multimeter with Temperature and Microamps
The Fluke 116 Digital Multimeter provides the features you need to quickly troubleshoot HVAC equipment
The Fluke 116 HVAC multimeter was specifically designed for HVAC professionals. It has everything you need to quickly troubleshoot problems with HVAC equipment and flame sensors, including a built-in thermometer to measure temperatures up to 400°C (752°F) and microamps to test flame sensors. The Fluke 116 digital multimeter also measures resistance, continuity, frequency, and capacitance. And the large white LED backlight makes it easy to see results even in poorly lit areas.
The Fluke 110 Series has five true-rms digital multimeters, each for specific users. The compact instruments offer convenient one-handed operation and a backlit display with large, easy-to-read digits.
Other useful features:
- Digital multimeter designed specifically for HVAC professionals
- Includes built-in thermometer to measure temperature from -40°C to z400°C (-40°F to 752°F)
- Provides microamps to test flame sensors
- Features low input impedance to helps prevent false readings due to ghost voltage
- Presents a large white LED backlight for working in poorly lit areas
- Measures resistance, continuity, frequency, and capacitance
- Provides Min/Max/Average to record signal fluctuations
- Comes with a holster with probe holders for easy storage
- Features a compact ergonomic design for one-handed operation
- Fits into optional ToolPak™ magnetic hanger for hands-free operation
- CAT III 600 V safety rated"" For HVAC technicians, building maintenance
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Meter Type
- Digital
- Measurement Type
- AC Voltage
- DC Voltage
- Resistance
- Continuity
- Capacitance
- Diode Test
- Temperature
- AC Current
- DC Current
- Frequency
- True RMS
- Yes
- Minimum AC Voltage Measurement
- 6 V
- Maximum AC Voltage Measurement
- 600 V
- Minimum DC Voltage Measurement
- 6 V
- Maximum DC Voltage Measurement
- 600 V
- Maximum AC Current Measurement
- 600 µA
- Maximum DC Current Measurement
- 600 µA
- Minimum Resistance Measurement
- 600 Ohm
- Maximum Resistance Measurement
- 40 Mega Ohm
- Minimum Capacitance Measurement
- 0F
- Maximum Capacitance Measurement
- 0.009999F
- Minimum Temperature Measurement
- -40°F (-40°C)
- Maximum Temperature Measurement
- 752°F (400°C)
- Minimum Frequency Measurement
- 99.99 Hz
- Maximum Frequency Measurement
- 50 kHz
- Application/Usage
- Electrical
- HVAC
- Features
- Backlight
- Built-in Thermometer
- Display & Graphics
- Display Counts
- 6000
- Battery Information
- Battery Chemistry
- Alkaline
- Physical Characteristics
- Weight (Approximate)
- 1.21 lb
- Miscellaneous
- Package Contents
- 116 HVAC Multimeter with Temperature and Microamps
- 4 mm Silicone Test Lead Set
- 80BK Integrated Temperature Probe
- Holster
- Installed 9 V Battery
- User Manual
- Certifications & Standards
Safety
- IEC 61010-1: Pollution Degree 2
- IEC 61010-2-033: CAT III 600V
