The UCS C240 M4 LFF server is the newest 2-socket, 2U rack server from Cisco, designed for both performance and expandability over a wide range of storage-intensive infrastructure workloads from big data to collaboration.
The enterprise-class UCS C240 M4 LFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the Intel® Xeon E5-2600 v3 and v4 series processor family that delivers the best combination of performance, flexibility and efficiency gains. In addition, the UCS C240 M4 LFF server provides 24 DIMM slots, up to 6 PCI Express (PCIe) 3.0 slots, up to 12 front-loading LFF drives plus two (optional) internal SFF SATA boot drives for a total of 14 internal drives.
The C240 M4 server includes a modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC) without consuming a PCI slot in addition to 2 x 1 GbE embedded (on the motherboard) LOM ports. These features combine to provide outstanding levels of internal memory and storage expandability along with exceptional performance.
The Cisco UCS C240 M4 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Series
- C240 M4
- Product Type
- Server
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 2
- Processor Manufacturer
- Intel
- Processor Type
- Xeon
- Processor Model
- E5-2650 v4
- Processor Core
- Dodeca-core (12 Core)
- Processor Speed
- 2.20 GHz
- Memory
- Standard Memory
- 256 GB
- Maximum Memory Supported
- 1.50 TB
- Memory Technology
- DDR4 SDRAM
- Total Number of Memory Slots
- 24.0
- Controllers
- Controller Type
- Serial ATA
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 10
- I/O Expansions
- Number of Total Expansion Bays
- 12
- Number of 3.5" Bays
- 12
- Hot Swappable Bays
- Yes
- Display & Graphics
- Graphics Controller Manufacturer
- Matrox
- Graphics Controller Model
- G200e
- Graphics Memory Capacity
- 8 MB
- Network & Communication
- Ethernet Technology
- 40 Gigabit Ethernet
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported
- 2
- Physical Characteristics
- Form Factor
- Rack
- Rack Height
- 2U
- Height
- 3.4"
- Width
- 19"
- Depth
- 30.2"
- Weight (Approximate)
- 67.46 lb
