Basic Functions
- Printing speed up to 5 ips (127 mm/sec)
- Fully compatible with market-leading programming languages
- Supporting stand-alone configuration mode by visual LED
- Smart switch programming languages without setting the mode
User-Friendly Design
- Easy paper loading with adjustable paper guide and holder
- Simply set up media sensor
- Optional peeler
- Compatible with label design software; BIXOLON's Label Artist™, Seagull's BarTender® and BarTender® UltraLite for BIXOLON
All in one Plus™ Interface
- Standard: USB
- Optional: USB + Serial + Ethernet
- General Information
- Manufacturer
- Bixolon America, Inc
- Manufacturer Website Address
- http://www.bixolon.com
- Brand Name
- Bixolon
- Product Type
- Direct Thermal Printer
- Technical Information
- Recommended Use
- Label Print
- Print Color Capability
- Monochrome
- Maximum Mono Print Speed
- 5 in/s
- Maximum Print Resolution (dpi)
- 203
- Maximum Print Length
- 39.37"
- Maximum Print Width
- 4.09"
- Barcode Symbology Supported
- TLC 39
- QR Code
- Maxi Code
- Micro PDF-417
- PDF417
- Data Matrix
- Code 49
- AZTEC
- Codablock
- IMB
- POSTNET
- Plessey
- Code 11
- Code 39
- Code 93
- Codabar
- Code 128
- EAN-13
- EAN-8
- Interleaved 2 of 5
- LOGMARS
- MSI
- UPC/EAN
- GS1 DataBar (RSS-14)
- UPC-A
- UPC-E
- Industrial 2 of 5
- Standard 2 of 5
- 1D
- 2D
- Real Time Clock
- No
- Application/Usage
- Warehouse
- Logistic
- Manufacturing
- Retail
- Features
- Compact
- Connectivity Technology
- Wired
- Fonts Included
- 10 SLCS Resident Bitmap Fonts
- 5 BPL-E Resident Bitmap Fonts
- One BPL-Z Resident Scalable Font
- One SLCS Resident Scalable Font
- 16 BPL-Z Resident Bitmap Fonts
- UTF-8
- UTF-16LE
- UTF-16BE
- Print Technology
- Direct Thermal
- Memory
- Standard Memory
- 64 MB
- Flash Memory
- 128 MB
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- Network & Communication
- Ethernet
- Yes
- Ethernet Technology
- Ethernet
- Display & Graphics
- Screen Size
- 4"
- Media Types & Handling
- Media Type
- Label
- Black Mark
- Notch
- Continuous Label
- Fanfold
- Media Sensor
- Transmissive Media Sensor
- Reflective Media Sensor
- Head Open Sensor
- Low Ribbon Sensor
- Media Thickness
- 7.87 mil
- Maximum Roll Diameter
- 5"
- Maximum Label Width
- 4.65"
- Fonts & Emulation
- Language Emulation
- BPL-E
- BPL-Z
- SLCS
- ZPL II
- EPL
- Power Description
- Power Source
- AC Supply
- Frequency
- 50 Hz
- 60 Hz
- Environmental Conditions
- Operating Temperature
- 32°F (0°C) - 104°F (40°C)
- Operating Relative Humidity
- 10% - 80%
- Storage Temperature
- -4°F (-20°C) - 140°F (60°C)
- Storage Relative Humidity
- 10% - 90%
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 6.6"
- Width
- 7.1"
- Depth
- 8.7"
- Weight (Approximate)
- 3.75 lb
- Miscellaneous
- Platform Supported
- PC
- Mac
- Energy Star
- Yes
