- General Information
- Manufacturer
- Altronix Corporation
- Manufacturer Website Address
- http://www.altronix.com
- Brand Name
- Altronix
- Product Line
- eBridge
- Product Type
- Transceiver/Media Converter
eBridge100ST EoC transceiver transmits data at 100Mbps, Full Duplex over Coax cable to a paired eBridge receiver and provides power in a PoE+ compliant format to an enabled device/camera. The eBridge receiver is available in various options (see compatibility list below/Altronix.com) and is powered by an external midspan, such as the Altronix Netway series. The receiver passes PoE+ power over the same coax cable to the eBridge100ST transceiver, which, in turn, passes this power to an enabled IP camera/device. These plug and play units facilitate cost-effective solutions for IP devices. They can be installed at distances greater than 300m. They provide a simple way to replace legacy analog products with new IP devices over existing coax. eBridge100ST is compatible with the following Altronix receivers: eBridge100RM, eBridge400PCRM, eBridge800PCRM or eBridge1600PCRM.
- Warranty
- Limited Warranty
- Lifetime
- Interfaces/Ports
- Total Number of Ports
- 1
- Network (RJ-45)
- Yes
- DVI
- No
- USB
- No
- Management Port
- No
- Number of PoE+ (RJ-45) Ports
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Maximum Distance Supported
- 0.50 km
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 10/100Base-TX
- Power Description
- Power Source
- PoE+
- Physical Characteristics
- Height
- 1.1"
- Width
- 2.3"
- Depth
- 2.6"
- Weight (Approximate)
- 3.52 oz
- Miscellaneous
- Environmentally Friendly
- Yes
- Country of Origin
- United States
- NDAA Compliant
- Yes
